RIFERIMENTO POLARE
POLAR REFERENCE

.


Technical data of acquisition

Back to Gallery

Basic object information

CCD Acquisition: Starlight Xpress SXV-H9 ( 16 Bit )
CCD Autoguide
: SBIG ST 7 XME 402 E
Optic configuration of the telescope: W.O.Megrez SDII 80 mm.
 F 555mm  f/d 6,9 ( apograde TMB ) + focal reducer f 6,3 Meade. Effective focal 352mm. f/d 4,4 frammed field 1,5 x 1,1 degrees

German Equatorial Mount:
Gemini G 41 Observatory Plus and FS 2 system control
Luminance integration time:
18 frame from 900" each with  filter Astronomik "hydrogen alfa13 nm "
Software used for the acquisition and the elaboration:
CCDSoft, Photoshop CS2 with KPT equalizer
+NoiseNinja, Astroart 4.0,
Date of acquisition:
July,August, 2008
Zone of acquisition:
Fixed posting of San Giuliano P.no ( Piacenza ) Italy
Author Astroimager:
Davide Romanini
- ASTRODAVID -



Name: NGC 6960 + 52 Cyg
Type of object: Supernova remnant
Magnitude: 7.0
Size: 60.0'x 9.0'

Position (epoch of date)
Right ascension: 20h 46m 4s
Declination: +30 45' 11"
Constellation: Cygnus





Click High Resolution
2202x2144 -
360 kb
