Technical data of acquisition

Back to Gallery

Basic object information

CCD Acquisition: Starlight Xpress SXV-H9
CCD Autoguide
: SBIG ST 7 XME 402 E
Temperature of exercise -13°C
Optic configuration of the telescope:
Re
fractor Skywatcher 120-900 mm. ED PRO + focal reducer Meade f 6,3
( focal equivalent and inclusive draught 630 mm.)
frammed field 58 x 43 arc minutes
German Equatorial Mount:
Gemini G 41 Observatory Plus and FS 2 system control
Luminance integration time:
12 frame from 600" each with  filter Astronomik H-alfa (13 nm)
06 frame from 300" each with  filter Astronomik CLS Profi
Integration color time:
R 4x300" G 3x600" B 3x600"
Software used for the acquisition and the elaboration:
CCDSoft, Photoshop CS, Astroart,
Date of acquisition: 2006
Zone of acquisition:
Fixed posting of San Giuliano P.no ( Piacenza ) Italy
Author Astroimager:
Davide Romanini
- ASTRODAVID -



Name: IC 5146 + Sh2-125
Popular name: Cocoon Nebula
Type of object: Open Cluster + Bright Nebula
Magnitude: 7.2
Apparent size: 20.0'x10.0'

Position (epoch of date)
Right ascension: 21h 53m 38s
Declination: +47° 17' 52"
Constellation: Cygnus

Click High Resolution
1392x1040 -
297 kb
